Arducam IMX477 12.3MP HQ Camera Module for Nvidia Jetson & Raspberry Pi CM3/3+/CM4 - High Resolution Camera Board for AI Vision, Computer Vision Projects, and DIY Robotics Applications
Free shipping on all orders over $50
7-15 days international
29 people viewing this product right now!
30-day free returns
Secure checkout
45774891
Description
Arducam just released this High Quality camera module for Jetson Board, an IMX477 camera board with 3 hole pitches. You can use this camera module on Jetson Board natively with ISP features. No hardware modifications required, just install the driver and you are good to go. KERNEL CAMERA DRIVER USED This camera relies on kernel drivers to work – one kernel version, one camera driver. Versions earlier than JetPack 4.3 (L4T 32.3.1) are not supported.Up or downgrading your OS leads to a kernel bump, and you’ll need to re-install a matching driver.Future JetPack/kernel updates require future drivers. When that happens, please allow us some time to process. And if you don’t see it released in time, kindly remind us. HQ Camera Board for Jetson Board SPECIFICATIONS Sensor: IMX477Optical Format: 1/2.3″ (diagonal 7.857mm)Resolution: 4056(H) x 3040(V) 12.3MPPixel Size: 1.55um x 1.55umIR Sensitivity: Visible lightInterface: 4-lane MIPI CSI-2Default Lens Mount: CS-MountFrame Rate: NVIDIA Jetson Orin NX/Orin Nano/AGX Orin: L4t 32.x: 4032x3040@30fps, 3840x2160@30fps, 1920x1080@60fps;L4t 35.x: 4032x3040@20fps, 3840x2160@30fps, 1920x1080@60fpsBoard Size: 38mm×38mmHole Pitch: Compatible with 29mm, 30mm, 34mm PACKING CONTENTS 1pcs 12.3MP IMX477 camera board with a dust cap for Jetsons 1pcs 11.8"(30cm) camera cable Customer Reviews Price Fov 80°(H) 75° (H) 75° (H)/50°(H) no data IR sensitivity Visible light Visible light Visible light Visible light EFL 3.9mm 3.9mm 3.9mm no data Interface type 2-lane MIPI CSI-2 2-lane MIPI CSI-2 2-lane MIPI CSI-2 2-lane MIPI CSI-2 F.NO F2.8 F2.8 F2.8 no data Support platform Nvidia Jetson Board and Xavier NX Raspberry Pi 4 Model B, Pi 3/3B+, and Pi Zero 2W Nvidia Jetson Board and Raspberry Pi CM3/3+ and CM4 Raspberry Pi 4 Model B, Pi 3/3B+, and Pi Zero 2W Sensor IMX477 IMX477 IMX477 IMX477 SKU B0251 B0272 B0273 B024001
Features
A Can't-Miss Update to IMX219 - Much better picture quality and lens flexibility, thanks to 53% more pixels, 92% larger pixel size, 192% larger imaging area, and a CS-Mount. Maximum still resolution at 4056 × 3040.
Accelerated by Jetson Hardware ISP Engine - Support NVIDIA Argus Camera plugin for H264 encoding, JPEG snapshots, as well as gain, exposure, framerate, and group, hold control.
Plug-and-Play - You don’t need any hardware modification to work with jetson platform. Just a driver needed. More convenient than RPI official HQ cameras.
4-Lane Camera for the Future - Route out all 4 data lanes to the camera connector for customized carrier boards with 4-lane CSI connector and future 4-lane camera driver updates.
Note：1. It can't work on the standard Raspberry Pi models (like Raspberry Pi 3/3B+/4) 2. This camera is compatible with Jetson Developer Kit, and it does not guarantee to support other third-party boards.
